Tool Vault Elite XL 84” 23-Drawer Roller Cabinet with Hutch and 2 Side Lockers

For current pricing and availability, please follow this link.

The Tool Vault® line of professional tool boxes are crafted to withstand the harshest conditions of a full-time mechanics environment.

ManufacturerTool Vault
SKUTV-84Combo5
Dimensions140" W x 30" D x 72¾" H
Shipped Weight2,633 lbs
Warranty5 Year Limited Warranty
Drawer Capacity250 lbs / 500 lbs
FinishHigh Gloss Powder Coat

From: $13,950.00

The Tool Vault® line of professional tool boxes are crafted to withstand the harshest conditions of a full-time mechanics environment. The ToolVault® brand brings you professional grade toolboxes at D.I.Y. prices, ideal for industry professionals and home enthusiasts. The ToolVault® XL 84 Inch Roller Cabinet with Hutch and 2 Side Lockers is a heavy duty, high quality toolbox featuring a drawer load rating of 250 pounds (500lb. on larger drawers), heavy-duty spring loaded casters, and full-width locking handle drawer pulls, a hutch with adjustable shelf & pegboard and retracting door, 2 side lockers with 2 shelves and 3 drawers each and a stainless steel work surface.

The TV-8430H Hutch will arrive as a knock-down that requires assembly. Please reference this guide for instructions on how to install your hutch.

Matching Locks
Not all tool box combination sets will be shipped with the same number lock for each piece. We can provide you with matching locks after you set up your new tool box at no charge. All you need to do is note the lock number on the base cabinet and call us at 888-289-1952 and let us know your order number and how many locks you need. We will then ship them out at no charge.

Excellent Toolbox

Packaging The packaging top notch. They package these toolboxes well. The chest came packaged in a wooden crate on a pallet. Open the crate and then you have chest in a cardboard box wrapped in plastic. There are supports under the chest that prevent any sagging during shipping and around all the casters there are strips that would prevent rolling. The hutch is shipped on top of the chest and it too is packaged well. Plan to have help or some lifting equipment getting it off the chest because it is heavy. The lockers are also packaged well. I ordered two and they each came on a small pallet. Both of my lockers came sitting on the smaller pallets on one larger pallet. This made the unboxing a little challenging so you will need help getting the off the pallets. All in all, the unboxing took some time and wasn’t too bad just have help. Delivery I called the freight company as soon as I received the tracking information as instructed and they made my appointment and talked to me about any special situations they might encounter during the delivery. On the day of the delivery the driver called me about 30 minutes before arrival. My toolbox went into a detached shop and the driver backed down my driveway and right up to the roll up door. My toolbox came on two pallets and the driver unloaded them and put them in my shop. The delivery went smooth except for the inspection of the toolbox. Strictly Toolboxes tell you not sign to for the delivery until you have inspected the toolbox. The driver unloaded and was gone before I realized it. I didn’t sign anything. Lucky for me my toolbox wasn’t damaged at all. The Toolbox The quality of this toolbox is as good if not better than the Mac Tools toolbox that it’s replacing as my main toolbox. The assembly of all of it will require help lifting the hutch. The hutch is attached to the chest, so you have to drill through the stainless-steel top. To do this remove two screws found on the underside of the top. Reaching in the top drawer and feel a little left and right of center. The top was marked so drilling wasn’t difficult. The lockers come with a set of casters installed that help you get them into place before you… Read more “Excellent Toolbox”

Ken

Reviews

There are no reviews yet.

Be the first to review “Tool Vault Elite XL 84” 23-Drawer Roller Cabinet with Hutch and 2 Side Lockers”

Your email address will not be published. Required fields are marked *

Specifications

Product Overview
Manufacturer
Tool Vault
SKU
TV-84Combo5
Dimensions
140" W x 30" D x 72¾" H
Net Weight
2,127 lbs
Shipped Weight
2,633 lbs
Warranty
5 Year Limited Warranty
Toolbox Construction
Shell Gauge
16
Drawer Gauge
18
Caster Channel Gauge
11
Color
Black, Blue, Lime Green, Orange, White
Finish
High Gloss Powder Coat
Lock Style
Tubular Coded
Qty Side Handles
2
Work Surface
Stainless Steel Top
Corner Trim
Aluminum
Drawer Information
# of Drawers
29
Sets of Drawer Slides
42
Drawer Liner Type
Premium non-slip Mesh
Drawer Latch Type
Locking Handle
Storage Capacity
Drawer Slide Type
Roller Bearing
Drawer Capacity
250 lbs / 500 lbs
Total Square Inches
20,468
Total Cubic Inches
193,862
Caster Information
# of Casters
8
Caster Capacity
1050 lbs per caster
Caster Type
2 Rigid / 8 Swivel Spring Loaded
Caster Upgrade
N/A

Product Overview

Manufacturer
Tool Vault
SKU
TV-84Combo5
Dimensions
140" W x 30" D x 72¾" H
Net Weight
2,127 lbs
Shipped Weight
2,633 lbs
Warranty
5 Year Limited Warranty
Product Overview

Toolbox Construction

Shell Gauge
16
Drawer Gauge
18
Caster Channel Gauge
11
Color
Black, Blue, Lime Green, Orange, White
Finish
High Gloss Powder Coat
Lock Style
Tubular Coded
Qty Side Handles
2
Work Surface
Stainless Steel Top
Corner Trim
Aluminum
Toolbox Construction

Drawer Information

# of Drawers
29
Sets of Drawer Slides
42
Drawer Liner Type
Premium non-slip Mesh
Drawer Latch Type
Locking Handle
Drawer Information

Storage Capacity

Drawer Slide Type
Roller Bearing
Drawer Capacity
250 lbs / 500 lbs
Total Square Inches
20,468
Total Cubic Inches
193,862
Storage Capacity

Caster Information

# of Casters
8
Caster Capacity
1050 lbs per caster
Caster Type
2 Rigid / 8 Swivel Spring Loaded
Caster Upgrade
N/A
Caster Information

Layout

Drawer #
Drawer DimensionsW" x D" x H"
Drawer Capacity
Sets of Drawer Slides
Cubic In
SQ In
TotalN/AN/A42193,86220,468
113.5265.25500 lbs.21,843351
247.25265.25500 lbs.26,4501,229
313.5265.25500 lbs.21,843351
413.5262.25250 lbs.1790351
547.25262.25250 lbs.12,7641,229
613.5262.25250 lbs.1790351
713.5262.25250 lbs.1790351
847.25262.25250 lbs.12,7641,229
913.5262.25250 lbs.1790351
1013.5262.25250 lbs.1790351
1122.125262.25250 lbs.11,294575
1222.125262.25250 lbs.11,294575
1313.5262.25250 lbs.1790351
1413.5265.25500 lbs.21,843351
1522.125265.25500 lbs.23,020575
1622.125265.25500 lbs.23,020575
1713.5265.25500 lbs.21,843351
1813.52611.25500 lbs.23,861351
1922.125265.25500 lbs.23,020575
2022.125265.25500 lbs.23,020575
2113.52611.25500 lbs.23,861351
2222.125265.25500 lbs.23,020575
2322.125265.25500 lbs.23,020575
HUTCH8028.37524N/AN/A49,5162,141
SIDE LOCKER 1
124211.75250 lbs.1882504
224211.75250 lbs.1882504
3242110.5250 lbs.15,292504
SHELF 1272824N/AN/A18,144756
SHELF 2272824N/AN/A18,144756
SIDE LOCKER 2
124211.75250 lbs.1882504
224211.75250 lbs.1882504
3242110.5250 lbs.15,292504
SHELF 1272824N/AN/A18,144756
SHELF 2272824N/AN/A18,144756
Layout Image
